| Brand Name : | FANBAO |
| Model Number : | F37, F47, F57, F67, F77, F87, F97, F107, F127, F157 FA37, FA47, FA57, FA67, FA77, FA87, FA97, FA107, FA127, FA157 FF37, FF47, FF57, FF67, FF77, FF87, FF97, FF107, FF127, FF157 FAF37, FAF47, FAF57, FAF67, FAF77, FAF87, FAF97, FAF107, FAF127, FAF157 |
| Certification : | CE |
| Price : | negotiation |
| Payment Terms : | T/T |
| Supply Ability : | 100sets per month |
| Delivery Time : | 8-15work days |
The F series reducer is manufactured in combination with international technical requirements and has a high scientific and technological content.
Space saving, reliable and durable, high overload capacity, power up to 90KW or more.
The F series parallel shaft helical gear reducer has low energy consumption, superior performance and an efficiency of over 95%.
The parallel shaft helical gear reducer has low vibration, low noise and high energy saving. It adopts high-quality segment steel material, rigid cast iron box, and the gear surface undergoes high-frequency heat treatment.
After precision machining, the parallelism of the shaft and the accuracy of positioning are ensured. All of these constitute the gear drive assembly. The reducer is equipped with various motors, forming mechatronics, which fully guarantees the quality characteristics of the gear motor products.
Advantages of choosing F series gear reducer
Apart of type specification :
| SIZE | 37 | 47 | 57 | 67 | 77 | 87 | 97 | 107 | 127 | 157 |
| DF DFA DFF DKAZ DFAF DFAZ | ||||||||||
| INPUT POWER RATING(KW) | 0.18-0.30 | 0.18-3.0 | 0.18-5.5 | 0.18-5.5 | 0.37-11 | 0.75-22 | 1.1-30 | 2.2-45 | 7.5-90 | 11-260 |
| RATIO | 3.81-128.51 | 5.06-189.39 | 5.18-199.70 | 4.21-228.99 | 4.20-271.92 | 4.12-270.64 | 4.68-270.64 | 6.20-255.25 | 4.63-172.33 | 12.07-270.18 |
| MAX TORQUE(N.m) | 200 | 400 | 600 | 820 | 1500 | 3000 | 4300 | 7840 | 12000 | 18000 |
| WEIGHT(KG) | 13 | 18 | 34 | 55 | 90 | 150 | 260 | 402 | 700 | 950 |
Mounting position and Position of the motor terminal box :
Why choose us :
|
|
